LiFePo4-48200T
CBB/KOYAMA
8507600090
48V LiFeP04 Battery
Summary
LFPTL LiFePo4 series is a complete range of 48V LiFePO4 (Lithium Iron phosphate) battery products, for a wide variety of applications, such as telecom base station, UPS, renewable energy system, etc., with advanced life, standard size, light weight and strong environmental adaptability.
Technical Features
• LiFePO4 (Lithium Iron phosphate) battery
• High energy density, Light weight, saving space.
• Long cycle life for deep cycle.
• Fast charge capability
• Integrated Battery Manage System (BMS) to ensure battery safety and reliability.
• Support parallel connection to increase capacity
• LED status and alarm indication
• Low self-discharge rate
• No memory effect
• No gassing
• Maintenance free
Applications:
Wireless Hut back-up power
Wireless Repeater back-up
Fiber-Optic access network back-up power
Outdoor Billboard lighting
48V Switchgear & Control Back-up Power
Long duration Industrial UPS Systems
FTTB & LAN/WIFI Connection Power
street & Highway Monitoring & Surveillance
General Specification
| Model | Nominal | Rated | Approx Dimension(mm) | Remarks |
| Voltage | Capacity | Length*Width*Height | ||
| V | Ah | (don't include the handle) | ||
| LiFePo4-4810S | 48V | 10 | 442*290*44 | Can not in parallel |
| LiFePo4-4820S | 48V | 20 | 442*330*88 | Can not in parallel |
| LiFePo4-4850C | 48V | 50 | 442*442*132 | Can in parallel |
| LiFePo4-4850T | 48V | 50 | 442*442*132 | Can in parallel |
| LiFePo4-4875C | 48V | 75 | 442*399*177 | Can in parallel |
| LiFePo4-48100F | 48V | 100 | 500*230*260 | Can in parallel |
| LiFePo4-48100T | 48V | 100 | 442*431*177.5 | Can in parallel |
| LiFePo4-48100E15 | 48V | 100 | 442*450*132 | Can in parallel |
| LiFePo4-48150T | 48V | 150 | 442*495*177 | Can in parallel |
| LiFePo4-48200T | 48V | 200 | 442*560*244 | Can in parallel |
| Parameter information subject to the contract, here for your reference only. | ||||
