CBB® NPFG series gel batteries are designed with front terminal structure. The perfect design ensures NPFG Gel battery the high reliability and makes the installation quite simple and safe when placed on a standard relay rack tray or in a closed cabinet. Adopt Flat plates with gel electrolyte. This new technology leverages on the advantages of the AGM and Gel technology to provide better cycle performance versus the AGM technology and a shorter time discharge performance as compared with the Gel technology. NPFG Series gel battery is designed with high energy density and suitable for 19", 23" rack or cabinet, and also offers options of top connection and side of monoblocks connection. NPFG Series battery can be equipped with central gas collection system according to the requirement of customer.
Quantity: | |
---|---|
Model No (Data Sheet) | Rated Voltage (V) | Rated Capacity (Ah) | Dimension | Weight | Terminal | ||||||||
Length | Width | Height | Total Height | kg | pound | ||||||||
mm | inch | mm | inch | mm | inch | mm | inch | ||||||
12 | 55/10HR | 277 | 10.91 | 106 | 4.17 | 223 | 8.78 | 223 | 8.78 | 16.1 | 35.4 | T2 | |
12 | 80/10HR | 562 | 22.13 | 114 | 4.49 | 188 | 7.40 | 188 | 7.40 | 25.1 | 55.2 | T3 | |
12 | 100/10HR | 507 | 19.96 | 110 | 4.33 | 223 | 8.78 | 223 | 8.78 | 29.5 | 64.9 | T5 | |
12 | 110/10HR | 394 | 15.51 | 110 | 4.33 | 286 | 11.26 | 286 | 11.26 | 30.6 | 67.3 | T5 | |
12 | 125/10HR | 552 | 21.73 | 110 | 4.33 | 239 | 9.41 | 239 | 9.41 | 38.2 | 84.0 | T5 | |
12 | 150/10HR | 551 | 21.69 | 110 | 4.33 | 288 | 11.34 | 288 | 11.34 | 44.2 | 97.2 | T5 | |
12 | 155/10HR | 560 | 22.05 | 125 | 4.92 | 280 | 11.02 | 280 | 11.02 | 45.4 | 99.9 | T5 | |
12 | 160/10HR | 551 | 21.69 | 110 | 4.33 | 288 | 11.34 | 288 | 11.34 | 44.7 | 98.3 | T5 | |
12 | 175/10HR | 546 | 21.50 | 125 | 4.92 | 316 | 12.44 | 324 | 12.76 | 53.7 | 118.1 | T5 | |
12 | 180/10HR | 560 | 22.05 | 125 | 4.92 | 316 | 12.44 | 316 | 12.44 | 54.2 | 119.2 | T5 | |
12 | 190/10HR | 560 | 22.05 | 125 | 4.92 | 316 | 12.44 | 316 | 12.44 | 55.5 | 122.1 | T5 | |
12 | 200/10HR | 560 | 22.05 | 125 | 4.92 | 316 | 12.44 | 316 | 12.44 | 57.2 | 125.8 | T5 |
• Gel technology applied in NPFG range batteries.
• Front-access terminal connections for fast and easy installation and maintenance
• Suitable for 19", 23" rack or cabinet
• Excellent special lead-tin-calcium formula alloy for Grids and plates
• Mircoporous glass mats in low resistance as separator
• Self-regulating pressure relief valve
• 12+ years expectant Life under full float service at 25℃(77℉)
• 19" and 23" standard power cabinet
• communication system, microwave station, mobile base station, data center,
radio / broadcasting station
• Power system of special network or local area network
• Emergency lighting and signal system
• UPS, Standby power, etc
