Golf, Utility Vehicle And NEV Gel Deep-Cycle Battery

Golf and Utility Vehicles / NEV batteries are built to deliver superior performance, durability and reliability; these batteries utilize the highest quality components and meet the challenges of the toughest, hilliest courses in the world.

The utmost gel technology is engineered with an advanced feature set that provides outstanding sustained performance and total energy output, delivering the exceptional quality and reliability CBB batteries are known for.
CBB Gel deep-cycle long-range golf and electric vehicle battery delivers 35% more travel time between recharging, enabling consumers to embark on longer excursions.

Durability, reliability and proven technology mean you can depend on CBB batteries for consistent performance day in and day out.
  • DCG225-6
  • 85072000
  • deep cycle gel battery with long life and high temperature performance
Model No Industry No Rated Voltage (V) Capacity (Ah) Dimension Weight Terminal Type
Length Width Height Total Height kg
 mm mm  mm  mm
6V-GEL DEEP-CYCLE BATTERY FOR Golf, Utility Vehicle And NEV
DCG210-6.pdf GC2/T105 6 210 260 180 247 252 29.6 T5/AP
DCG225-6.pdf DIN-TE35 6 225 243 187 275 275 30.6 T5
DCG225-6AP.pdf DIN-TE35AP 6 225 243 187 275 275 30.6 AP
DCG226-6.pdf GC2/T125 6 226 260 180 247 252 30.2 T5/AP
DCG250-6.pdf GC2/T145 6 226 260 187 265 272 34.7 T5/AP
8V-GEL DEEP-CYCLE BATTERY FOR Golf, Utility Vehicle And NEV
DCG170-8.pdf GC8-T875 8 170 260 182 266 271 34.2 T5
DCG200-8.pdf GC8H-T890 8 200 260 182 295 301 38.2 T5
12V-GEL DEEP-CYCLE BATTERY FOR Golf, Utility Vehicle And NEV
DCG150-12B.pdf T1275 12 150 328 182 267 272 44.4 T5/AP

• The success of DCG batteries comes from the internationally superior Gel technology

• Excellent energy storage capacity combined with high reliability

• Designed in accordance with IEC 60254-1

• 700 Cycles at 75%DOD

• 7 years design life at 20 °C ambient temperature (80% remaining capacity from C20)

• Grid plate construction consisting of a lead calcium alloy

• Very low gassing due to the internal gas recombination

• High cycle service life

• Better temperature resistance performance

• Excellent deep cycle performance

• Superior low current discharge performance

• Better charge acceptability

• Better safety performance and reliability

• High Performance price/ratio and low yearly operating cost

• Non-Spillable construction design

• Safety valve installation for explosion proof

• Low self discharge characteristic

• ABS containers and covers (UL94HB, UL94V-0 optional)

• Gel-batteries are designed to be operated within a wide temperature range –40° C and +55° C

• Maintenance-free (no topping up) motive power batteries in gel technology

• Completely recyclable

• other power drive equipment, etc





.personnel transport

.turf maintenance


.golf cart


.people mover

.police transport

.utility vehicle

.burden carrier

.personnel carrier

.utility vehicle

cbb battery terminal 1cbb battery terminal 2

1.DCG series-Deep Cycle Gel Battery Brochure
