- Classic silver fish li ion battery, discharge on bottom with 2 pins.(Actually there are 4 pins but we only connector two)
- The case could be lengthen to increase capacity.
1. Technical Data | |
Model No. | UPP-S004-2 Silver Fish Lithium ion Battery |
Battery Type | Li(NiCoMn)O2 18650 |
Nominal Voltage | 24V |
Nominal Capacity | 10Ah |
Cell Brand | 2500mah Brand 18650 3C Cells |
Max Discharge Constant Current | 15A |
Charger | 29.4V 2A |
Standard Charge Current | 5A |
Max Charge Current | Customize |
Charge Cut-Off Voltage | 29.4V |
Discharge Cut-Off Voltage | 19.6V |
Cycle | 600~800 Cycles |
2. Basic Data | |
Size | 390*110*75mm |
Battery Net Weight | 2.5Kg |
Recommended Motor | 24V 100W-300W Electric City Bike Scooter etc |
Warranty | 12 month once cargo is delivered |
Case Material | Aluminum Alloy |
Discharging Temprature | -20~60 Celsius |
Charging Temprature | 0~45 Celsius |
Product Description
- Classic silver fish li ion battery, discharge on bottom with 2 pins.(Actually there are 4 pins but we only connector two)
- The case could be lengthen to increase capacity.
1. Technical Data | |
Model No. | UPP-S004-2 Silver Fish Lithium ion Battery |
Battery Type | Li(NiCoMn)O2 18650 |
Nominal Voltage | 24V |
Nominal Capacity | 10Ah |
Cell Brand | 2500mah Brand 18650 3C Cells |
Max Discharge Constant Current | 15A |
Charger | 29.4V 2A |
Standard Charge Current | 5A |
Max Charge Current | Customize |
Charge Cut-Off Voltage | 29.4V |
Discharge Cut-Off Voltage | 19.6V |
Cycle | 600~800 Cycles |
2. Basic Data | |
Size | 390*110*75mm |
Battery Net Weight | 2.5Kg |
Recommended Motor | 24V 100W-300W Electric City Bike Scooter etc |
Warranty | 12 month once cargo is delivered |
Case Material | Aluminum Alloy |
Discharging Temprature | -20~60 Celsius |
Charging Temprature | 0~45 Celsius |
